FEATURES:
- It makes it extremely fast and simple to produce accurate bends up to 190 degrees in tubing up to 1-3/8".
- Simply set the desired degree of bend with the thumb wheel and that number appears on the digital display.
- As soon as the trigger is pressed, the actual degrees of bend are displayed, up until the bend is completed.
- The robust 1700 watt motor and heavy duty gear box are built to last.Bends are made quickly at 3.5 rpm.
SPECIFICATIONS:
Model | DB32 |
---|
Voltage | 110-120V~ 50-60Hz, 220-240V~ 50-60Hz |
---|
Power Input | 1700W |
---|
No Load Min-1 | 3.5 |
---|
Max. Capacity | 35mm (1-3/8") |
---|
Soft Start | With |
---|
Dimensions(LxWxH) | 630mm x 230mm x 183mm |
---|
Net Weight (Machine Only) | 14kg (30.86 Lbs) |
---|
Standard Accessories: Tripod, Velcro Strap
