FEATURES:
- 230mm plunge cut saws with 85mm depth of cut respectively.
- Outstanding accuracy and control when used in conjunction with the optional guide rail.
SPECIFICATIONS:
| Model |
DS2300 |
| Power Input |
1600W |
| Voltage |
110-120V~ 50-60Hz, 220-240V~ 50-60Hz |
| No Load Min-1 |
5000 |
| Bevel Capability |
0 - 45 deg. |
| Max. Blade Diameter |
230mm (9 in.) |
| Available Arbor Hole Diameters* |
30mm, 25.4mm (1 in.), 20mm |
| Max. Cutting Straight |
85mm (3-3/8") |
| Depth 45 Deg. Bevel |
60mm (2-3/8") |
| Soft Start & Overload Protection |
With |
| Dimensions(LxWxH) |
428mm x 246mm x 311mm |
| Net Weight |
7.7 kg (16.98 Lbs) |
Standard Accessories: Hex Wrench M5
