Product Description: AERO SPEED TRAILER TYPE AIR SCREW COMPRESSOR, UDS-125S Series
Overview:
The AERO SPEED Trailer Type Air Screw Compressor is engineered for high-performance, reliable operations in demanding environments. Featuring robust construction and advanced technology, the UDS series—comprising models UDS-125S, UDS-185S, and UDS-265S—delivers unmatched efficiency and portability for industrial and construction applications.
Key Features:
- Rotary Twin Screw Air Compressor: Delivers consistent, reliable compressed air with minimal pulsation and reduced maintenance.
- Water-Cooled, 4-Stroke Engine: Ensures superior cooling performance and long engine life even in tough working conditions.
- Electric Start: Facilitates quick and effortless startup, maximizing operational uptime.
- Heavy-Duty Trailer Mounting: Provides easy transportation and deployment across worksites.
- Multiple Air Outlets: Enables simultaneous tool operation, increasing productivity and versatility.
- Generous Fuel and Air Receiver Tanks: Extended run times and optimized efficiency.
Model Specifications:
| Model | UDS-125S | UDS-185S | UDS-265S | |---------------|------------------------|------------------------|-----------------------| | Engine | FAW 4DW91-56G2 | ISUZU 4JB1-C | ISUZU 4JB1T-C | | Engine Power | 41 kW @ 2,650 rpm | 45 kW @ 3,000 rpm | 62 kW @ 3,000 rpm | | Cylinders | 3 | 4 | 4 | | Bore x Stroke | 90 x 100 mm | 93 x 102 mm | 93 x 102 mm | | Intake Method | Natural Intake | Natural Intake | Turbo Charged | | Displacement | 2.54 L | 2.771 L | 2.771 L | | Fuel Consumption | 9.3 L @ 75% load | 10.2 L @ 75% load | 14.1 L @ 75% load | | Compressor Type | Rotary Twin Screw | Rotary Twin Screw | Rotary Twin Screw | | Free Air Delivery | 3.5 m³/min | 5.2 m³/min | 7.5 m³/min | | Operating Pressure | 7 kg/cm² | 7 kg/cm² | 7 kg/cm² | | Air Outlets | 2 pcs | 3 pcs | 3 pcs | | Receiver Tank | 0.027 m³ | 0.027 m³ | 0.08 m³ | | Fuel Tank | 60 L | 60 L | 90 L | | Dimensions (mm) | 3100 x 1640 x 1690 | 3100 x 1640 x 1690 | 3320 x 1850 x 1750 | | Net Weight | 720 kg | 1180 kg | 1290 kg |
(For higher output, the CUMMINS 6BT5.9-C150 engine offers 110 kW power, 11 m³/min air delivery at 10 kg/cm², 5 air outlets, 0.105 m³ receiver tank, 120 L fuel tank, 4200 x 2000 x 2050 mm package size, and 1970 kg net weight.)
Recommended Applications:
- Road, bridge, and tunnel construction
- Mining and quarrying operations
- Field servicing and heavy mobile equipment
- Industrial manufacturing sites
Expert Choice: The AERO SPEED UDS series sets a new standard in portable compressed air solutions. With advanced rotary twin screw technology and highly efficient water-cooled engines from leading brands—FAW, ISUZU, and CUMMINS—this range offers low fuel consumption, exceptional free air delivery, and rock-solid reliability. Trust the AERO SPEED Trailer Type Air Screw Compressor to maximize your productivity and deliver professional performance wherever your next job takes you.
